Algemeen
Artikelnummer
21-00402
Merk
ProLights
Artikelnummer fabrikant
ECLPANELTWCXLPACK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGB+WW - Full Color
Vermogen1500W
Aansturing
Stand Aloneselectable mode through 4 rotatory knobs
Lichtbron
Lichtbron1.500W RGB + Warm White LED
CCT CCT control range from 1.800K to 20.000K, + / - green correction, tungsten emulation
Luminous flux136'060lm @3.200 K with LD filter
Lux1'892lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI93 @3.200 K; 93.6 @5.600 K
R995.7 @3.200 K; 88,9 @5.600 K
TLCI93 @5.600 K
TM30 Rf91 @3.200 K; 89,9 @5.600 K
TM30 Rg103 @3.200 K; 103 @5.600 K
Optiek
Lens typemedium density diffusion panel (interchangeable)
Extra optieken see available accessories
Min. Zoombereik109
Kleuren
Kleurmenging RGB + Warm White
Wit macro's1.800 K - 20.000K with 28 K resolution
Kleurenwiel virtual colour wheel with macros
Effecten
Macros Gels library on-board
Control Resolution 16-bit dimmer, colours
Behuizing
Kleur behuizingZwart
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM, Art-Net, sACN, W-DMX
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Display accu self-charging battery backup
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik1.600W
Output (at 230V)1 units on a single power line
Power factor>0,96
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
DC Connector XLR 4p
IP waardeIP20
Logistieke eigenschappen
Hoogte verpakking
141.9 cm
Breedte verpakking
60 cm
Diepte verpakking
171.1 cm
Gewicht verpakking
222 kg
