Lamp eigenschappen
KleursysteemRGB+WW - Full Color
Vermogen30W
Aansturing
Stand Aloneselectable mode through 3 rotatory knobs
Lichtbron
Lichtbron30W RGB + Warm White
CCTCCT control range from 2.200K to 15.000K, + / - green correction, tungsten emulation
Luminous flux1'829lm @3.200 K with LD filter
Lux690lx @1 m
Levensverwachting lichtbron> 50.000 h
CRI94,6 @3.200 K; 94,9 @5.600 K
R997,1 @3.200 K; 96 @5.600 K
TLCI92 @5.600 K
TM30 Rf97,7 @3.200 K; 89,3 @5.600 K
TM30 Rg102,5 @3.200 K; 102,3 @5.600 K
Optiek
Lens typemagnetic light density diffusion panel (interchangeable)
Extra optiekensee available accessories
Min. Zoombereik105
Kleuren
KleurmengingRGB + Warm White
Wit macro's2.800 K - 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generator4 controllable sections
Macrosseveral pre-built pixel macros with adjustable speed
Control Resolution16-bit dimmer, colours
Behuizing
Kleur behuizingZwart, black
Materiaalsturdy policarbonate body
Aansturing
ProtocollenCRMX+W-DMX, DMX512, RDM
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1+ENPTWCYCABLE) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur0° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 36.000 Hz
Elektrische eigenschappen
NetvoedingDC 12V
Max. stroomverbruik32 W
Power factor>0,97
Batterij11.1V lithium, Ja
Fysieke eigenschappen
Koelingpassive cooling and fan-free
BevestigingM5 and 1/4'' threaded insert for easy installation
StroomaansluitingUSB-C
DC ConnectorUSB type C
Oplaad connectieUSB type C
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
41 cm
Breedte verpakking
53 cm
Diepte verpakking
19 cm
Gewicht verpakking
13 kg
