Algemeen
Artikelnummer
21-00399
Merk
ProLights
Artikelnummer fabrikant
ECLNANOPANELTWC
Garantie
2 jaar
Aansturing
Stand Aloneselectable mode through 3 rotatory knobs
Lichtbron
Lichtbron30W RGB + Warm White
CCT CCT control range from 2.200K to 15.000K, + / - green correction, tungsten emulation
Luminous flux1'829lm @3.200 K with LD filter
Lux690lx @1 m
Levensverwachting lichtbron > 50.000 h
CRI94,6 @3.200 K; 94,9 @5.600 K
R997,1 @3.200 K; 96 @5.600 K
TLCI92 @5.600 K
TM30 Rf97,7 @3.200 K; 89,3 @5.600 K
TM30 Rg102,5 @3.200 K; 102,3 @5.600 K
Optiek
Lens typemagnetic light density diffusion panel (interchangeable)
Extra optieken see available accessories
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2,800 K - 10,000K
Kleurenwiel virtual colour wheel with macros
Effecten
FX generator4 controllable sections
Macros several pre-built pixel macros with adjustable speed
Control Resolution 16-bit dimmer, colours
Body
Kleur behuizing black
Behuizing sturdy policarbonate body
Aansturing
Protocolen CRMX+W-DMX, DMX512, RDM
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1+ENPTWCYCABLE) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur 0° ~ +45°
LED Control flicker free frequency with adjustable PWM
Selecteerbare PWM frequentie 600 ~ 36.000 Hz
Elektrische eigenschappen
Netvoeding DC 12V
Max. stroomverbruik32 W
Power factor>0,97
Batterij11.1V lithium
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging M5 and 1/4'' threaded insert for easy installation
DC Connector USB type C
Oplaad connectieUSB type C
IP waarde20
