Lamp eigenschappen
KleursysteemRGB+WW - Full Color
Vermogen70W
Lichtbron
CCTCCT control range from 2.800K to 10.000K, + / - green correction, tungsten emulation
Luminous flux3'188 lm @Full
Lux2'356lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI92,3 @3.200K; 90,9 @5.600K
R989,8 @3.200K; 97,8 @5.600K
TM30 Rf> 90
TM30 Rg< 107
Optiek
Extra optieken(optional) 20° and 40° - see available accessories
Min. Zoombereik11, 11
Kleuren
KleurmengingRGB + Warm White
Wit macro's2.700 K -10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-built macros with adjustable speed
Control Resolution16-bit dimmer and color control
Behuizing
Kleur behuizingZwart
Aansturing
DMX kanalen4/6/10/3 ch in legacy mode | 1/5/11/17ch
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (not included)
RDMfor remote addressing and parameter configuration
Electronics
Dimmerlinear 0 - 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
BedrijfstemperatuurTa 0 to +45 °C (+32 to +113 °F)
Selecteerbare PWM frequentie1000 to 25000 Hz (selectable steps)
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Fysieke eigenschappen
Koelingfan-free with natural convection
Bevestiginghanging bracket for floor positioning with "Quick-Lock" system
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Gewicht4 kg
Overige eigenschappen
Lichtbron7x10W RGB + Warm White LED
Multicolor LED
Logistieke eigenschappen
Hoogte verpakking
25 cm
Breedte verpakking
30 cm
Diepte verpakking
23.5 cm
Gewicht verpakking
5.35 kg
