Algemeen
Artikelnummer
21-00608
Merk
ProLights
Artikelnummer fabrikant
ARCSHM1808VWC5M
Garantie
2 jaar
Aansturing
Stand Aloneavailable through DATAMASTER external coder (not included)
Lichtbron
Lichtbron18x4W Variable White LED
CCTCCT control through dedicated DMX channel
Lux(8°) 1'553 lx; (8°+20°) 378 lx; (8°+40°) 154 lx; (8°+60°) 118 lx; (8°+1060°) 279 lx;
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI>85
Optiek
Extra optiekensee available accessories
Kleuren
KleurmengingVariable White
Effecten
Macrosbuilt-in white presets
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 5 / 9channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik80W
Output (at 230V)15 units on a single power line
Power factor>0,94
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingmoulded IP signal IN/OUT connectors
Logistieke eigenschappen
Gewicht verpakking
5.75 kg
