Algemeen
Artikelnummer
21-00607
Merk
ProLights
Artikelnummer fabrikant
ARCSHM1808FCC5M
Garantie
2 jaar
Aansturing
Stand Aloneavailable through DATAMASTER external coder (not included)
Lichtbron
Lichtbron18x4W RGBWW LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(8°) 2'385 lm; (8°+20°) 2'353 lm; (8°+40°) 2'242 lm; (8°+60°) 2'262 lm
Lux(8°) 3'641 lx; (8°+20°) 712 lx; (8°+40°) 264 lx; (8°+60°) 181 lx; (8°+10°x60°) 450 lx
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI>80
Optiek
Extra optiekensee available accessories
Kleuren
KleurmengingRGB + Warm White
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosbuilt-in white presets
Behuizing
Kleur behuizingRAL 7012
Materiaalsturdy aluminum profile
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 5 / 9 / 12 / 14channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik80W
Output (at 230V)18 units on a single power line
Power factor>0,94
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingmoulded IP signal IN/OUT connectors
Stroomaansluitingmoulded IP power IN/OUT connectors
IP waardeIP66 for outdoor installations
Logistieke eigenschappen
Gewicht verpakking
5.75 kg
