Algemeen
Artikelnummer
21-00405
Merk
ProLights
Artikelnummer fabrikant
ARCSHINES1815FC
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
AansturingDMX, RDM
Vermogen36W
SerieArcShine
Aansturing
Stand Aloneavailable through DATAMASTER external coder (not included)
Lichtbron
Lichtbron18x2W RGBW LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(15°) 1'168 lm; (15°+20°) 1'047 lm; (15°+60°) 1.030 lm; (15°+10°x60°) 1'339
Lux(15°) 646 lx; (15°+20°) 222 lx; (15°+60°) 25 lx; (15°+10°x60°) 141 lx; (15°+30°x60°) 113lx
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI>80
Optiek
Extra optiekensee available accessories
Kleuren
Kleurmenging4 in 1 RGBW
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosbuilt-in white presets
Behuizing
Tilt anglemanual 180°
Kleur behuizingGrijs
MateriaalAluminium
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 5 / 9 / 12 / 14channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F)
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Voedingstype230V AC
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik40W
Output (at 230V)15 units on a single power line
Power factor>0,94
Fysieke eigenschappen
Koelingpassive cooling and fan-free
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingmoulded IP signal IN/OUT connectors
Stroomaansluitingmoulded IP power IN/OUT connectors
IP waardeIP66
Montage mogelijkhedenOpbouw
Logistieke eigenschappen
Gewicht verpakking
4 kg
