Algemeen
Artikelnummer
21-00527
Merk
ProLights
Artikelnummer fabrikant
ARCSPOTDOTVWGY
Garantie
2 jaar
Lamp eigenschappen
SerieArcSpot
Lichtbron
Lichtbron1 x 20W Variable White LED
CCTlinear CCT control
Luminous flux690 @full
Lux2370lx @5 m full
Levensverwachting lichtbron> 90.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI97 @WW; 92 @CW; 96 @full
R992 @full
TLCI97 @WW; 99 @CW; 98 @full
TM30 Rf>96 @WW; >93 @CW; >94 @full
TM30 RgSource life expectancy: > 90.000 hrs
Optiek
Extra optiekensee available accessories
Kleuren
Kleurmengingtunable white
Kleurenwielbuilt-in white presets
Effecten
Macrosseveral pre-built macros with adjustable speed
Behuizing
Kleur behuizingRAL 7012
Materiaalsturdy die-cast aluminium body, scratch resistant paint (C5M as standard)
Aansturing
ProtocollenDMX512, RDM
DMX kanalen2 / 3 / 4 / 9channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayuser interface through DATAMASTER external coder (not included)
Firmware upgradeyes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F)
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik24W
Power factor> 0,9
Fysieke eigenschappen
Bevestigingbracket for hanging and positioning
Signaal aansluitingmoulded IP signal IN/OUT connectors
Stroomaansluitingmoulded IP power IN connector
IP waarde66 for outdoor installations
Logistieke eigenschappen
Hoogte verpakking
21.5 cm
Breedte verpakking
20 cm
Diepte verpakking
19 cm
Gewicht verpakking
1.7 kg
