Algemeen
Artikelnummer
21-00414
Merk
ProLights
Artikelnummer fabrikant
ECLSOFTLINEARIP
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGB+WW - Full Color
Vermogen230W
Lichtbron
Lichtbron230W RGB + Warm White LED
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux12'994lm @4.000 K with LD filter
Lux220lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI92 @3.200 K; 93 @5.600 K
R996 @3.200 K; 92 @5.600 K
TLCI87 @5.600 K
TM30 Rf91 @3.200 K; 90 @5.600 K
TM30 Rg107 @3.200 K; 106 @5.600 K
Optiek
Lens typehigh-quality glass lens optics
Extra optiekenMountable Medium Density diffusion filter (included)
Min. Zoombereik103
Kleuren
KleurmengingRGB + Warm White
Wit macro's2,800 K - 10,000K with 28 K resolution
Kleurenwielvirtual colour wheel with macros
Effecten
Control Resolution16-bit dimmer, colours
Behuizing
Kleur behuizingZwart, black
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, W-DMX
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 36.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik250W
Output (at 230V)8 units on a single power line
Power factor>0,97
DC spanning48Vdc
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1, Seetronic powerCON TRUE IP65 IN/OUT
DC ConnectorXLR 3p for 48V
IP waarde65 for temporary outdoor use (*), IP65
Logistieke eigenschappen
Hoogte verpakking
17.5 cm
Breedte verpakking
111.5 cm
Diepte verpakking
21 cm
Gewicht verpakking
9.6 kg
