Algemeen
Artikelnummer
21-00626
Merk
ProLights
Artikelnummer fabrikant
ECLFWHPIPVWBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen450W
Aansturing
Stand Alone4 pushable RGB backlit encoder
Lichtbron
Lichtbron450W Variable White LED
CCTCCT control range from 2.800K to 6.500K
Luminous flux(19°) 13'419 lm; (26°) 16'662 lm; (50°) 15'037 lm @5.600 K
Lux(19°) 6'667 lx; (26°) 4'537 lx; (50°) 1'236lx @5 m 5.600 K
Levensverwachting lichtbron> 50.000 h
CRIup to 98
R9up to 98
TLCIup to 99
TM30 Rf96 @3200K; 96 @5600K
TM30 Rg103 @3200K; 102 @5600K
Optiek
Lens typehigh-quality glass lens optics
Focusmanual
Extra optiekenoptional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / 90° zoom 15°-30° / zoom 25°-50°
BedieningHandmatig
Kleuren
Kleurmengingtunable white
Effecten
Roterende gobo'soptional, see available accessories
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingZwart
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalenfrom 1 channel to 16channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) through dedicated software
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free operation
Selecteerbare PWM frequentie1282 ~ 20.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik450W
Output (at 230V)5 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
StroomaansluitingPowerCon TRUE1
IP waardeIP65
