Algemeen
Artikelnummer
21-00588
Merk
ProLights
Artikelnummer fabrikant
ECLCTPLUSHPIPBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBRBMA - Full Color
Vermogen450W
Aansturing
Stand Alone 4 pushable RGB backlit encoder
Lichtbron
Lichtbron450W 6 colour LEDs source
CCT CCT control range from 1.800K to 20.000K, + / - green correction, tungsten emulation
Luminous flux14000 lm
Levensverwachting lichtbron > 50.000 h
CRI96
R997
Optiek
Lens type high-quality glass lens optics
Focus manual
Extra optiekenoptional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / 90° zoom 15°-30° / zoom 25°-50°
Min. Zoombereik5
Max. Zoombereik50
BedieningHandmatig
Kleuren
KleurenwielLEE filter emulation and RGB / HSI / CMY input mode selectable
Effecten
Roterende gobo'soptional, see available accessories
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingZwart
Materiaal weatherproof IP65 construction with die-cast magnesium alloy
Aansturing
Protocollen DMX512, RDM, CRMX
DMX kanalenfrom 1 channel to 30channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade via DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) through dedicated software
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F) Ta
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik470W
Output (at 230V)7 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waardeIP65
Logistieke eigenschappen
Hoogte verpakking
34.5 cm
Breedte verpakking
72 cm
Diepte verpakking
32 cm
Gewicht verpakking
14.5 kg
