Algemeen
Artikelnummer
21-00587
Merk
ProLights
Artikelnummer fabrikant
ECLCTPLUSHPBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBRBMA - Full Color
Vermogen450W
Aansturing
Stand Alone4 pushable RGB backlit encoder
Lichtbron
Lichtbron450W 6 colour LEDs source
CCTCCT control range from 1.800K to 20.000K, + / - green correction, tungsten emulation
Luminous flux14'000 lm
Levensverwachting lichtbron> 50.000 h
CRI96
R997
Optiek
Lens typehigh-quality glass lens optics
Focusmanual
Extra optiekenoptional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / 90° zoom 15°-30° / zoom 25°-50°
Min. Zoombereik5
Max. Zoombereik50
BedieningHandmatig
Kleuren
KleurenwielLEE filter emulation and RGB / HSI / CMY input mode selectable
Effecten
Roterende gobo'soptional, see available accessories
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingRAL 9004, Zwart
Materiaalsturdy die-cast magnesium body
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalenfrom 1 channel to 30channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) through dedicated software
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik470W
Output (at 230V)7 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
34.5 cm
Breedte verpakking
71 cm
Diepte verpakking
32 cm
Gewicht verpakking
11.8 kg
