Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen260W
Lichtbron
Lichtbron91x3W high-power white LED
CCTfrom 2.700K to 6.500K
Luminous flux(26° only TU) 3'696 lm; (26° only DY) 4'406 lm; (26°) 7'951lm @full
Lux(26° only TU) 1'289 lx; (26° only DY) 1'524 lx; (26°) 2'759lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI(only TU) 97,7; (only DY) 95,7; (@full) 96.3
R9(only TU) 86,2; (only DY) 90,9; (@full) 90,5
TLCI(only TU) 97; (only DY) 97; (@full) 98
TM30 Rf(only TU) >92; (only DY) >90; (@full) >92
TM30 Rg(only TU) >96; (only DY) >99; (@full)
Optiek
Lens typeHD anti-reflection lenses with achromatic coating
Focusmanual
BedieningHandmatig
Kleuren
Kleurmengingwarm white + cold white
Wit macro's2.700K - 5.600K
Effecten
Roterende gobo's1 rotating gobo controlled on DMX
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingZwart
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen2 / 3 / 4 / 6 / 12channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik264W
Output (at 230V)11 units on a single power line
Power factor0,97
Fysieke eigenschappen
Koelinglow noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Logistieke eigenschappen
Hoogte verpakking
32 cm
Breedte verpakking
30 cm
Diepte verpakking
68 cm
Gewicht verpakking
13 kg
