Lichtbron
Lichtbron91x3W high-power white LED
CCT(TU) 3.200 K - (DY) 5.600K
Luminous flux(DY) 5°: 7'231 - 10°: 8'828 - 14°: 8'061 lm -19°: 7'664 lm - 26°: 9'826 lm - 36°: 9'707 lm - 50°: 9'017 lm - 70°: 11'708 lm @full
Lux(DY) 5°: 35'955 - 10°: 16'083 - 14°: 7'894 lx - 19°: 4'626 lx - 26°: 2'722 lx - 36°: 1'450 lx - 50°: 766 lx - 70°: 494lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >98; (DY) >97
R9(TU) >91; (DY) >97
TLCI(TU) >98; (DY) >98
TM30 Rf(TU) >94; (DY) >91
TM30 Rg(TU) >99; (DY) >99
Optiek
Lens type HD anti-reflection lenses with achromatic coating
Focus manual
Kleuren
Kleurmengingstatic white
Effecten
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Messen systeem3 layers blades system and fast rehabilitation of blade in case of out of frame blade
Body
Kleur behuizing black
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512, RDM
DMX kanalen2 / 3 / 4 / 5channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX2) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Display accu self-charging battery backup
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik264W
Output (at 230V)11 units on a single power line
Power factor0,97
Fysieke eigenschappen
Koeling low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN/OUT
IP waarde65 for temporary outdoor application, not for fixed installation
