Algemeen
Artikelnummer
21-00380
Merk
ProLights
Artikelnummer fabrikant
ECLCTPLUSIPBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBRBMA - Full Color
Vermogen260W
Aansturing
Stand Aloneselection of static colours, white presets, manual colours and built-in effects with adjus
Lichtbron
Lichtbron96x3W 6 colour custom LEDs source (red, green, blue, royal blue, mint, pc amber)
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(zoom 15°-30°) (min angle) 5'290 lm; (max angle) 6'664 lm - (zoom 25°-50°) (min
Lux(zoom 15°-30°) (min angle) 3'502 lx; (max angle) 1'800 lx - (zoom 25°-50°) (min
Levensverwachting lichtbron> 50.000 h
CRI93,7 @3.200 K; 97,6 @5.600 K
R998,6 @3.200 K; 98,2 @5.600 K
TLCI95 @5.600 K
TM30 Rf92 @5.600 K
TM30 Rg100,1 @5.600 K
Optiek
Lens typehigh-quality glass lens optics
Focusmanual
Extra optiekenoptional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50°
Min. Zoombereik20
Max. Zoombereik45
BedieningHandmatig
Kleuren
KleurmengingRGB, Royal Blue, Mint, PC Amber
Wit macro's2.800 K ~ 10.000K
KleurenwielLEE filter emulation and RGB / HSI / CMY input mode selectable
Effecten
Roterende gobo's1 rotating gobo controlled on DMX
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingRAL 9004, Zwart
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalenUNO / DUO / Basic / Standard / Extended / RAW Direct / RAW 16bit / XYchannel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included (through dedicated software)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik264W
Output (at 230V)7 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelinglow noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1, Seetronic powerCON TRUE IP65 IN/OUT
IP waarde65 for temporary outdoor application, not for fixed installation, IP65
Logistieke eigenschappen
Hoogte verpakking
31.5 cm
Breedte verpakking
68 cm
Diepte verpakking
30 cm
Gewicht verpakking
12.8 kg
