Lamp eigenschappen
KleursysteemRGBL - Full Color
Vermogen200W
Lichtbron
Lichtbron91x3W RGB + lime LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(5°) TBD; (10°) TBD; (14°) 4'619 lm; (19°) 5'133 lm; (26°) 6'100 lm; (36°)
Lux(5°) TBD; (10°) TBD; (14°) 4'321 lx; (19°) 2'567 lx; (26°) 1'711 lx; (36°)
Levensverwachting lichtbron> 50.000 h
CRI86 @ 3200K; 85 @ 5600K
TLCI82 @ 5600K
TM30 Rf84 @ 3200K
TM30 Rg109 @ 3200K
Optiek
Lens typehigh-quality glass lens optics
Focusmanual
Extra optiekenoptional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50
Min. Zoombereik20
Max. Zoombereik45
BedieningHandmatig, Pole operated
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGB + lime / full colour
Wit macro's2.700 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-build pixel macros with adjustable speed
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizingZwart, black
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen1 / 2 / 3RGB / 4RGBL / 5RGBL / 3 / 4 / 5 / 8 / 13 ch - Tungsten / 3.200 K / 5.400 K / 6.50
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik200W
Output (at 230V)10 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelinglow noise fan
Bevestigingbracket for hanging and positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Logistieke eigenschappen
Hoogte verpakking
29.5 cm
Breedte verpakking
33 cm
Diepte verpakking
63 cm
Gewicht verpakking
9 kg
