Algemeen
Artikelnummer
21-00374-OUTLET
Merk
ProLights
Artikelnummer fabrikant
STUDIOCOBPLUSTWWH
Garantie
2 jaar
Lichtbron
Lichtbron155W Tunable White LED
CCTCCT control through dedicated DMX channel
Luminous flux(20°) 3'809 - (36°) 3'510lm
Lux(34°) WW 331 lx - CW 434 lx - NW 732lx @3 m
Levensverwachting lichtbron> 30.000 h
CRIWW / CW > 95
Optiek
Lens typeparabolic reflector in combination with HD fresnel lens
Extra optiekenflood (without lens) - 38° (inc)
Kleuren
Kleurmengingtunable white
Wit macro's3.200 K ~ 7.500K
Behuizing
Kleur behuizingblack, white finishing available
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen2 / 4 / 7channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayblack OLED touch display
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik157W
Output (at 230V)12 units on a single power line
Power factor> 0,97
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingSeetronic powerCON waterproof IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
