Algemeen
Artikelnummer
21-00370-OUTLET
Merk
ProLights
Artikelnummer fabrikant
STUDIOCOBPFC2BK
Garantie
2 jaar
Lichtbron
Lichtbron150W COB RGBW / FC LED
CCTCCT control through dedicated DMX channel
Luminous flux(18°) 3'632lm
Lux(18°) 2'958lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typeparabolic reflector in combination with HD fresnel lens
Extra optieken38° (inc)
Kleuren
KleurmengingRGBW / FC
Kleurenwielvirtual colour wheel with macros
Behuizing
Kleur behuizingblack, white finishing available
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM
DMX kanalen4 / 6 / 10channel
Master/Slavefor synchronised operation of more units linked in a chain
Displayblack OLED touch display
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik140W
Output (at 230V)12 units on a single power line
Power factor0,96
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingSeetronic powerCON waterproof IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
