Algemeen
Artikelnummer
21-00603
Merk
ProLights
Artikelnummer fabrikant
ECLPARIPSVWBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen60W
Lichtbron
CCTCCT control through dedicated DMX channel
Luminous flux(15°) 3'438, (30°) 3'117, (60°) 3'258 @Full
Lux(15°) 1'840, (30°) 458, (60°) 169lx @5 m full
Levensverwachting lichtbron> 50.000 h
CRI96,9 @full; 96,2 @3'200K; 98 @5'600K
R991,2 @3'200K; 96,4 @5'600K
TLCI99 @full; 98 @3'200K; 99 @5'600K
TM30 Rf94,2 @full; 95,2 @3'200K; 93,4 @5'600K
TM30 Rg102,3 @full; 103,1 @3'200K; 100,5 @5'600K
Optiek
Lens diameter100mm
Lens typeparabolic reflector in combination with HD fresnel lens
Extra optieken(opt) 30°, 60°
Kleuren
Kleurmengingtunable white
Wit macro's2.700 K ~ 6.500K
Effecten
Macrosbuilt-in white presets
Behuizing
Kleur behuizingZwart
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, CRMX (optional)
DMX kanalen1 / 2 / 4 / 5 / 9 / 11channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik65W
Power factor> 0,93
Fysieke eigenschappen
Koelingnatural convection cooling enabled by a fanless design and a chassis engineered for passiv
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Gewicht2,8 kg
Overige eigenschappen
Lichtbron60W Variable White LED
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
21.5 cm
Breedte verpakking
38 cm
Diepte verpakking
35.5 cm
Gewicht verpakking
4.2 kg
