Algemeen
Artikelnummer
21-00509
Merk
ProLights
Artikelnummer fabrikant
ECLPARIPMVWBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen100W
Lichtbron
Lichtbron100W Variable White LED
CCT CCT control through dedicated DMX channel
Luminous flux(15°) 5'020lm @full
Lux(15°) 2'894lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI97,3 @full; 97,8 @2'700K; 97,3 @6'500K
R993,2 @full; 84,2 @2'700K; 96,5 @6'500K
TLCI98 @full; 97 @2'700K; 99 @6'500K
TM30 Rf94,4 @full; 95,8 @2'700K; 93 @6'500K
TM30 Rg102,1 @full; 99 @2'700K; 99,9 @6'500K
Optiek
Lens diameter172mm
Lens type parabolic reflector in combination with HD fresnel lens
Extra optieken(opt) 30°, 60°
Kleuren
Kleurmenging tunable white
Wit macro's2.700 K ~ 6.500K
Effecten
Macros built-in white presets
Behuizing
Kleur behuizingZwart, black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM, CRMX
DMX kanalen1 / 2 / 4 / 5 / 9 / 11channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F)
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik117W
Output (at 230V)24 units on a single power line
Power factor> 0,93
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1, Seetronic powerCON TRUE IP65 IN/OUT
IP waardeIP65
Gewicht4kg kg
Logistieke eigenschappen
Hoogte verpakking
27.5 cm
Breedte verpakking
40.5 cm
Diepte verpakking
30 cm
Gewicht verpakking
5.6 kg
