Algemeen
Artikelnummer
21-00494
Merk
ProLights
Artikelnummer fabrikant
ECLPARIPMFCBK
Garantie
2 jaar
Lichtbron
Lichtbron100W COB RGB+WW LED
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux(15°) 3'324 lm; (30°) 3'453lm @full
Lux(15°) 1'772 lx; (30°) 387lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI93,7 @3'200K; 91,1 @5'600K
R989 @3'200K; 88 @5'600K
TLCI77 @3'200K; 86 @5'600K
TM30 Rf90 @3'200K; 89 @5'600K
TM30 Rg109 @3'200K; 108 @5'600K
Optiek
Lens diameter172mm
Lens type parabolic reflector in combination with HD fresnel lens
Extra optieken(opt) 30°, 60°
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2.700 K ~ 10.000K
Effecten
Macros Gels library on-board
Body
Kleur behuizing black
Behuizing sturdy die-cast aluminium body
Aansturing
Protocolen DMX512, RDM, CRMX
DMX kanalen1 / 2 / 5 / 9 / 10 / 12 / 18channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° C / +45° C (-4° F / +113° F)
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik120W
Output (at 230V)24 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN/OUT
IP waarde65 for temporary outdoor application, not for fixed installations
