Lichtbron
Lichtbron18x20W RGB + Warm White LED
CCTCCT control, + / - green correction, tungsten emulation
Luminous fluxTBD
Lux3'936lx @5 m
Levensverwachting lichtbron> 50.000 h
CRITBD
R9TBD
TLCITBD
TM30 RfTBD
TM30 RgTBD
Optiek
Lens typedifferent optics available
Extra optiekenseveral filters available
Kleuren
KleurmengingRGB + Warm White
Wit macro's2.800 K - 10.000K with 28 K resolution
Kleurenwielvirtual colour wheel with macros
Effecten
Control Resolution16-bit dimmer, colours
Behuizing
Kleur behuizingblack
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512, RDM, Art-Net, sACN, W-DMX
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik250W
Output (at 230V)8
Power factor>0,97
Fysieke eigenschappen
Koelingactive, silent operation
Bevestiginghanging bracket for floor stand. Also can fit the fast quick lock OMEGA bracket
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingSeetronic powerCON TRUE IP65 IN/OUT
IP waarde65 for temporary outdoor use (*)
Logistieke eigenschappen
Hoogte verpakking
21.5 cm
Breedte verpakking
107.5 cm
Diepte verpakking
29 cm
Gewicht verpakking
14 kg
