Lichtbron
Lichtbron15x10W RGBW LEDs
CCT CCT control through dedicated DMX channel
Luminous flux(16° + diffused) 4'983 lm - (16°) 5'394lm @full
Lux(16° + diffused) 1'886 lm - (16°) 2'454lx @5 m full
Levensverwachting lichtbron > 30.000 h
Optiek
Extra optiekenmagnetic frost holder on board
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Wit macro's2.800 K - 10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros several pre-build pixel macros with adjustable speed
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512
DMX kanalen4 / 6 / 10 / 60 / 65channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter0 ~ 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
Display accu self-charging battery backup
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik161W
Output (at 230V)23 units on a single power line
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON waterproof IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
Logistieke eigenschappen
Hoogte verpakking
20.5 cm
Breedte verpakking
99.6 cm
Diepte verpakking
16 cm
Gewicht verpakking
8.6 kg
