Lichtbron
Lichtbron48x10W RGBW / FC LEDs
CCT CCT control through dedicated DMX channel
Luminous flux28'213lm @full
Lux(25°) 4'638lx @5 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Extra optieken10° / 15° / 45° / 40° filter / 10x60° filter / 30x60° filter
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Kleurenwiel virtual colour wheel with macros
Effecten
FX generatorsection effect with 4 horizontal individually select and control sections
Macros several pre-build macros with adjustable speed
Behuizing
Tilt angle0 - 150° with manual regulation
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM, W-DMX
DMX kanalen5 / 7 / 10 / 17 / 22channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -20° ~ +45°
LED Control flicker free frequency with adjustable PWM
Display accu self-charging battery backup
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik500W
Output (at 230V)5 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging hanging bracket for floor positioning with "Quick-Lock" system
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON waterproof IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
Logistieke eigenschappen
Hoogte verpakking
39.5 cm
Breedte verpakking
65 cm
Diepte verpakking
20.5 cm
Gewicht verpakking
16.1 kg
