Lichtbron
Lichtbron36x8W RGBW LED
Luminous flux9'678lm
Lux(25°) 5'300lx @3 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens diameter38mm
Extra optieken45° (optional)
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Wit macro's3.200 K ~ 10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros built-in white presets
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, W-DMX
DMX kanalen4 / 6 / 10channel
Master/Slave for synchronised operation of more units linked in a chain
Display touch - sensitive LED display
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur -20° ~ +45°
LED Control flicker free operation
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik245W
Output (at 230V)6 units on a single power line
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging bracket for hanging and positioning
Signaal aansluiting moulded IP signal IN/OUT connectors
Stroomaansluiting moulded IP power IN/OUT connectors
IP waarde65 for temporary outdoor application, not for fixed installation
Logistieke eigenschappen
Hoogte verpakking
30.3 cm
Breedte verpakking
58.7 cm
Diepte verpakking
10.2 cm
Gewicht verpakking
14.5 kg
