Lamp eigenschappen
KleursysteemKleurenwiel, RGBCMA - Full Color
Vermogen1000W
Lichtbron
CCTCCT control range from 2.200K to 15.000K, + / - green correction, tungsten emulation
Luminous flux(5,9°) 14'001 lm - (49,7°) 21'257 lm @Full
Lux(5,9°) 64'433 lx - (49,7°) 1'556lx @5 m full
Levensverwachting lichtbron> 40.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI98,8 @3.200K; 97,2 @5.600K
R997,1 @3.200K; 96,4 @5.600K
TLCI93 @3.200K; 97 @5.600K
TM30 Rf95 @3.200K; 94 @5.600K
TM30 Rg100 @3.200K; 101 @5.600K
Optiek
Lens diameter150mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik6
Max. Zoombereik50
Kleuren
Wit macro's2.700K - 6.500K
Kleurenwielopen+5 colour filters
Effecten
Roterende gobo's6 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frostlinear 0-100% from soft-edge to heavy diffusion
Gobo maatouter: 26,9 mm - image: 20 mm - thickness: up to 3 mm
Messen systeem4 shutter blades with position and ±35° angle adjustment, ±60° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Control Resolution16-bit dimmer, colours
EffectenAnimatiewiel, Focus, Frost, Gobo, Iris, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Aansturing
DMX kanalen43 / 48 / 49 / 53channel
Display2.4'' Color display
Firmware upgradevia DMX with UPBOXPRO (USB-DMX interface not included) or via Ethernet (Art-Net with DMX-W
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves5 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik1400W
Power factor> 0.95
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
StroomaansluitingPowerCon TRUE1
IP waardeIP20
Gewicht34kg kg
Overige eigenschappen
Lichtbron1000W 6 colour LEDs source with adjustable high color rendering
Multicolor LED
Logistieke eigenschappen
Hoogte verpakking
39 cm
Breedte verpakking
83.5 cm
Diepte verpakking
50 cm
Gewicht verpakking
37.5 kg
