Algemeen
Artikelnummer
21-00630
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROF500LTIP
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY
Vermogen500W
Lichtbron
CCTlinear CTO correction 2.700 K ~ 6.500 K
Luminous flux(4,2°) 15'370 lm - (50,1°) 24'649 lm @Full
Lux(4,2°) 121'742 lx - (50,1°) 1'924lx
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI> 70 (CCT 5.600K and CRI > 90 with filter on color wheel)
Optiek
Lens diameter156mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik4
Max. Zoombereik50
Kleuren
KleurmengingCMY colour system on 3 gradually fading colour wheels
Kleurenwielopen + high CRI filter + 5 colour colour filters
Effecten
FX generator2 prisms overlap for spectacular aerial effects
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Vaste gobo's8 fixed gobos + open
Prisma4f with bi-directional rotation
Linear prisma6f with bi-directional rotation
Frostdual soft-edge and heavy with one interchangeable element
Gobo maatouter: 25 mm - image: 20 mm - thickness: up to 3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Control Resolution16-bit dimmer
EffectenAnimatiewiel, Focus, Frost, Gobo, Iris, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 8 / 16-bit
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, CRMX
DMX kanalen43channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45° Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik788W
Output (at 230V)4 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Gewicht34 kg
Overige eigenschappen
Lichtbron500W White LED
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
37 cm
Breedte verpakking
57 cm
Diepte verpakking
83 cm
Gewicht verpakking
42 kg
