Algemeen
Artikelnummer
21-00618
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROF1200IP
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY, Kleurenwiel
Vermogen1200W
Lichtbron
CCTlinear CTO correction 2.700 K ~ 7.000 K
Luminous flux(5,4°) 21'906 lm - (50,9°) 54'599 lm @Full
Lux(5,4°) 125'003 lx (50,9°) 4'008lx @5 m full
Levensverwachting lichtbron> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI> 70 (CRI > 90 with High CRI filter on color wheel)
Optiek
Lens diameter185mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik5
Max. Zoombereik50
Kleuren
Kleurmenginglinear CMY
Kleurenwielopen + High CRI filter + 5 colour filters
Effecten
FX generatorprisms overlap for spectacular aerial effects
Roterende gobo's6 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Linear prisma6f with bi-directional rotation, indexing
Frostdual frost filter, soft-edge and heavy (one interchangeable)
Gobo maatpreliminary data: outer: 30 mm - image: 25 mm - thickness: 1,1 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Control Resolution16-bit dimmer
EffectenAnimatiewiel, Focus, Frost, Gobo, Iris, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingblack
Pan/Tilt resolutiebit 8 / 16-bit
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, CRMX
DMX kanalen45channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik1843W
Output (at 230V)1 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Gewicht55kg kg
Overige eigenschappen
Lichtbron1'400W White LED (driven @1'200W)
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
41.5 cm
Breedte verpakking
104.5 cm
Diepte verpakking
65.5 cm
Gewicht verpakking
65.7 kg
