Lamp eigenschappen
KleursysteemKleurenwiel
Vermogen120W
Lichtbron
CCTon wheel 3.200 K
Luminous flux(9,1°) 4'502 lm - (46,3°) 5'686 lm @Full
Lux(9,1°) 9'452 lx - (46,3°) 681lx @5 m full
Levensverwachting lichtbron> 30.000 h
Optiek
Lens diameter75mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik9
Max. Zoombereik46
Kleuren
Kleurenwielopen+8 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Vaste gobo's10 fixed gobos + open
Prisma3f with bi-directional rotation, indexing, interchangeable
Frostlinear 0 - 100% light frost filter, interchangeable
Gobo maat22,5 mm - image: 17 mm - thickness: up to 3 mm
Control Resolution16-bit dimmer
EffectenFocus, Frost, Gobo, Prisma, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Aansturing
ProtocollenDMX512, RDM
DMX kanalen20channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik238W
Output (at 230V)16 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingNeutrik XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP20
Gewicht14kg kg
Overige eigenschappen
Lichtbron120W high-power white LED
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
35 cm
Breedte verpakking
58 cm
Diepte verpakking
44 cm
Gewicht verpakking
15.2 kg
