Algemeen
Artikelnummer
21-00575
Merk
ProLights
MPN
JETPROFILE300LT
Artikelnummer fabrikant
JETPROFILE300LT
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY
Vermogen300W
Lichtbron
CCTon wheel 3.200 K, 4.500 K and 5.600K
Luminous flux(3,9°) 8'313 lm - (44,1°) 12'065 lm
Lux(3,9°) 88'597 lx (44,1°) 1'333lx @5 m
Levensverwachting lichtbron> 30.000 h
Optiek
Lens diameter140mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik4
Max. Zoombereik44
Kleuren
KleurmengingCMY colour system on 3 gradually fading colour wheels
Kleurenwiel9 dichroic filters on 3 independent colour wheels
Effecten
FX generatorprisms overlap for spectacular aerial effects
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing, interchangeable
Linear prisma4f with bi-directional rotation, indexing, interchangeable
Frostlinear 0 - 100% light frost filter, interchangeable
Gobo maatouter diameter: 20 mm; image diameter: 16 mm; thick: up to 3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Control Resolution16-bit dimmer
EffectenAnimatiewiel, Focus, Frost, Gobo, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalen(STD) 37 / (EXT) 42channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik491W
Output (at 230V)7 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingNeutrik XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waarde20
Gewicht21 kg
Overige eigenschappen
Lichtbron300W high-power white LED
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
50 cm
Breedte verpakking
80 cm
Diepte verpakking
60 cm
Gewicht verpakking
30 kg
