Algemeen
Artikelnummer
21-00574
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROFILE900HQ
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY
Vermogen900W
Lichtbron
CCTlinear CTO correction 2.700 K ~ 6.000 K
Luminous flux(5,4°) 13'969 lm - (med) 25'941 lm - (52°) 25'311 lm
Lux(5,4°) 74'135 lx - (med) 9'836 lx - (52°) 1'659lx @5 m
CRI96
R990
TLCI97
TM30 Rf>91
Optiek
Lens diameter185mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised 16-bit control with focus tracking
Min. Zoombereik5
Max. Zoombereik52
Kleuren
Kleurmenginglinear CMY
Kleurenwielopen + 6 colour filters
Effecten
FX generator2 prisms overlap for spectacular aerial effects
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Linear prisma6f with bi-directional rotation, indexing
Frostdual frost filter, soft-edge and heavy (one interchangeable)
Gobo maatouter: 30 mm - image: 25 mm - thickness: up to 3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Control Resolution16-bit dimmer
EffectenAnimatiewiel, Focus, Frost, Gobo, Iris, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, CRMX
DMX kanalen46channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik1310W
Output (at 230V)2 units on a single power line
Power factor> 0,97
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingNeutrik XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waarde20
Gewicht45 kg
Overige eigenschappen
Lichtbron900W White LED
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
43 cm
Breedte verpakking
97 cm
Diepte verpakking
60 cm
Gewicht verpakking
51.5 kg
