Algemeen
Artikelnummer
21-00573
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROFILE900
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY
Vermogen900W
Lichtbron
CCTlinear CTO correction 2.700 K ~ 7.000 K
Luminous flux(5,5°) 23'816 lm - (52°) 42'919 lm
Lux(5,5°) 126'304 lx - (52°) 3'060lx @5 m
Levensverwachting lichtbron> 20.000 h
CRI> 70 (CCT 6.000K and CRI > 90 with filter on color wheel)
Optiek
Lens diameter185mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised 16-bit control with focus tracking
Min. Zoombereik5
Max. Zoombereik52
Kleuren
Kleurmenginglinear CMY
Kleurenwielopen + high CRI filter + 5 colour filters
Effecten
FX generator2 prisms overlap for spectacular aerial effects
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Linear prisma6f with bi-directional rotation, indexing
Frostdual frost filter, soft-edge and heavy (one interchangeable)
Gobo maatouter: 30 mm - image: 25 mm - thickness: up to 3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
Control Resolution16-bit dimmer
EffectenAnimatiewiel, Focus, Frost, Gobo, Iris, Prisma, Profielmessen, Zoom
Behuizing
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, CRMX
DMX kanalen46channel
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45° Ta
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik1310W
Output (at 230V)2 units on a single power line
Power factor> 0,97
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingNeutrik XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waarde20
Gewicht45 kg
Overige eigenschappen
Lichtbron1000W White LED (driven @900W)
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
43 cm
Breedte verpakking
97 cm
Diepte verpakking
60 cm
Gewicht verpakking
51.5 kg
