Algemeen
Artikelnummer
21-00462
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROFILE600IP
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY, Kleurenwiel
Vermogen600W
Zoom7° - 62° motorised linear zoom
Lichtbron
Lichtbron600W White LED
CCTlinear CTO correction 2.700 K ~ 6.500 K
Luminous flux(7°) 14'877 lm - (62°) 21'200lm
Lux(7°) 57'569 lx - (62°) 1'144lx @5 m
Levensverwachting lichtbron> 30.000 h
CRI> 70 (CCT 5.600K and CRI > 90 with high CRI filter on color wheel)
Optiek
Lens diameter150mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik7
Max. Zoombereik62
Kleuren
Kleurmenginglinear CMY
Kleurenwielopen + 5,600K high CRI filter + 6 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 29,9 mm - image: 22 mm - thickness: up to 3 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
EffectenFocus, Frost, Gobo, Iris, Prisma, Profielmessen
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 8 / 16-bit
Materiaalweatherproof IP65 construction
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, W-DMX + CRMX
DMX kanalen29 / 39 / 54channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik750W
Power factor>0,97
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1, Seetronic powerCON TRUE IP65 IN
IP waarde65 for temporary outdoor use (*), IP65
Gewicht40 kg
Logistieke eigenschappen
Hoogte verpakking
55.5 cm
Breedte verpakking
84.5 cm
Diepte verpakking
45 cm
Gewicht verpakking
45 kg
