Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen350W
Zoom4° - 52° motorised linear zoom
Lichtbron
Lichtbron19x20W RGBW Osram Ostar LEDs
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 3'019 lm - (52°) 5'337lm @full
Lux(4°) 23'781 lx - (52°) 682lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehoneycomb gapless plano-convex optics
Min. Zoombereik10
Max. Zoombereik45
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Control Resolution16-bit dimmer
Behuizing
Pan angle540°
Tilt angle233°
Kleur behuizingWit, see variants
Pan/Tilt resolutiebit 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM
DMX kanalen23channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik350W
Output (at 230V)7 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koelingforced air with fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Gewicht15 kg
Logistieke eigenschappen
Hoogte verpakking
35 cm
Breedte verpakking
49 cm
Diepte verpakking
58 cm
Gewicht verpakking
16 kg
