Algemeen
Artikelnummer
21-00443
Merk
ProLights
Artikelnummer fabrikant
ASTRAWASH7PIXWH
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen220W
Zoom4° - 56° motorised linear zoom
Lichtbron
Lichtbron7x40W RGBW Osram Ostar LEDs
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 2'013 lm - (56°) 3'543lm @full
Lux(4°) 18'360 lx - (56°) 364lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehoneycomb gapless plano-convex optics
Min. Zoombereik4
Max. Zoombereik56
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-built pixel macros with adjustable speed
Control Resolution16-bit dimmer
EffectenLed ring
Behuizing
Pan angle540°
Tilt angle233°
Kleur behuizingWit, see variants
Pan/Tilt resolutiebit 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, Klingnet, sACN, W-DMX
DMX kanalenmain personality 24 / 27 / 39channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik225W
Output (at 230V)up to 13 units on a single power line
Power factor> 0,93
Fysieke eigenschappen
Koelingforced air with fan
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Gewicht8 kg
Logistieke eigenschappen
Hoogte verpakking
29 cm
Breedte verpakking
34 cm
Diepte verpakking
45 cm
Gewicht verpakking
10 kg
