Algemeen
Artikelnummer
21-00441
Merk
ProLights
Artikelnummer fabrikant
ASTRAPROFILE400
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY, Kleurenwiel
Vermogen400W
Zoom6,5° - 50° motorised linear zoom
Lichtbron
Lichtbron400W White LED
CCTlinear CTO correction 2.700 K ~ 7.000 K
Luminous flux(6,5°) 9'143 - (50°) 17'598lm
Lux(6,5°) 37'468 lx (50°) 1'690lx @5 m
Levensverwachting lichtbron> 30.000 h
CRI> 70 (CCT 5.600K and CRI > 90 with filter on color wheel)
Optiek
Lens diameter130mm
Lens typeHD anti-reflection lenses with achromatic coating
Focusmotorised
Min. Zoombereik6
Max. Zoombereik50
Kleuren
Kleurmenginglinear CMY
Kleurenwiel5,600K high CRI filter + 6 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 25,7 mm - image: 19 mm - thickness: 1,1 mm
Messen systeem4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete fr
Animatiewielanimation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
EffectenFocus, Gobo, Iris, Prisma, Profielmessen
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 8 / 16-bit
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, ArtNet, sACN, W-DMX + CRMX
DMX kanalen29 / 39 / 54channel
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curvesselectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free frequency with adjustable PWM
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik620W
Output (at 230V)4 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Gewicht28 kg
Logistieke eigenschappen
Hoogte verpakking
36 cm
Breedte verpakking
73 cm
Diepte verpakking
51 cm
Gewicht verpakking
33 kg
