Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen350W
Zoom4° - 52° motorised linear zoom
Lichtbron
Lichtbron19x20W RGBW Osram Ostar LEDs
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 3'019 lm - (52°) 5'337lm @full
Lux(4°) 23'781 lx - (52°) 682lx @5 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens type honeycomb gapless plano-convex optics
Min. Zoombereik4
Max. Zoombereik52
Kleuren
Kleurmenging RGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Control Resolution 16-bit dimmer
Behuizing
Pan angle540°
Tilt angle233°
Kleur behuizingZwart
Pan/Tilt resolutiebit 16-bit
Materiaal aluminium structure with high-resistance polycarbonate cover
Aansturing
Protocollen DMX512, RDM, W-DMX
DMX kanalen23channel
Display LCD high resolution colour display with autoflip
Firmware upgrade yes, via USB - DMX interface (UPBOX2) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik350W
Output (at 230V)7 units on a single power line
Power factor> 0,96
Fysieke eigenschappen
Koeling forced air with fan
Bevestiging any position with quick-lock omega brackets
Pan / tilt lock for transportation and maintenance
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waardeIP20
Gewicht15 kg
Logistieke eigenschappen
Hoogte verpakking
35 cm
Breedte verpakking
58 cm
Diepte verpakking
49 cm
Gewicht verpakking
15 kg
