Algemeen
Artikelnummer
21-00379
Merk
ProLights
Artikelnummer fabrikant
ASTRAWASH37PIX
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen1480W
Zoom4° - 54° motorised linear zoom
Lichtbron
Lichtbron37x40W RGBW Osram Ostar LEDs
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 8'452 lm - (54°) 17'898lm @full
Lux(4°) 73'522 lx - (54°) 2'140lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehoneycomb gapless plano-convex optics
Extra optiekendiffuser on outer pixel ring
Min. Zoombereik4
Max. Zoombereik54
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-built pixel macros with adjustable speed
Control Resolution16-bit dimmer, colours
EffectenLed ring, Pixel Control
Behuizing
Pan angle540°
Tilt angle233°
Kleur behuizingRAL 9004, Zwart
Materiaalaluminium structure with high-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, Klingnet, sACN, W-DMX
DMX kanalenmain personality 23 / 30 / 44 / 52channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +40°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik1227W
Output (at 230V)3 units on a single power line
Power factor> 0,97
Fysieke eigenschappen
Koelingforced air with fan
Bevestigingany position with quick-lock omega brackets
Pan / tilt lockfor transportation and maintenance
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN/OUT connectors, PowerCON TRUE1
IP waarde20, IP20
Gewicht26 kg
Logistieke eigenschappen
Hoogte verpakking
43 cm
Breedte verpakking
75 cm
Diepte verpakking
63 cm
Gewicht verpakking
32.5 kg
