Algemeen
Artikelnummer
21-00376
Merk
ProLights
Artikelnummer fabrikant
ASTRAWASH7PIXIP
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen220W
Zoom4° - 56° motorised linear zoom
Lichtbron
Lichtbron7x40W RGBW Osram Ostar LEDs
CCTCCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 2'013 lm - (56°) 3'543lm @full
Lux(4°) 18'360 lx - (56°) 364lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehoneycomb gapless plano-convex optics
Min. Zoombereik4
Max. Zoombereik56
Kleuren
KleurmengingRGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-built pixel macros with adjustable speed
Control Resolution16-bit dimmer
EffectenLed ring
Behuizing
Pan angle540°
Tilt angle233°
Kleur behuizingRAL 9004, Zwart
Pan/Tilt resolutie16bit
Materiaalweatherproof IP65 construction
Aansturing
ProtocollenDMX512, RDM, Art-Net, Klingnet, sACN, W-DMX
DMX kanalenmain personality 24 / 27 / 39channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +45°
LED Controlflicker free operation
Display accuself-charging battery backup
Selecteerbare PWM frequentie600 ~ 50.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik220W
Output (at 230V)13 units on a single power line
Power factor> 0,93
Fysieke eigenschappen
Koelingforced air with fan
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1, Seetronic powerCON TRUE IP65 IN
IP waarde65 for temporary outdoor application, not for fixed installation, IP65
Gewicht11 kg
Logistieke eigenschappen
Hoogte verpakking
40 cm
Breedte verpakking
50 cm
Diepte verpakking
30 cm
Gewicht verpakking
12 kg
