Algemeen
Artikelnummer
21-00367
Merk
ProLights
Artikelnummer fabrikant
ASTRABEAM260IP
Garantie
2 jaar
Lichtbron
Lichtbron260W PRO OSRAM SIRIUS HRI Lamp
CCT on wheel 2.500 K and 3.200 K + CTB
Lux1'984'000lx @5 m
Levensverwachting lichtbron 6.000 h
Optiek
Lens diameter140mm
Lens type HD anti-reflection lenses with achromatic coating
Focus motorised
Kleuren
Kleurenwiel10 colour filters
Effecten
FX generator2 prisms overlap for spectacular aerial effects
Vaste gobo's15 fixed gobos + open
Prisma8f with bi-directional rotation, indexing
Linear prisma6f with bi-directional rotation, indexing
Frost linear 0 - 100% frost filter
Control Resolution 16-bit dimmer
Body
Pan angle540°
Tilt angle230°
Kleur behuizing RAL 9004
Pan/Tilt resolutie16bit
Behuizing weatherproof IP65 construction
Aansturing
Protocolen DMX512, RDM, Art-Net, sACN, W-DMX
DMX kanalen17channel
Display LCD high resolution colour display with autoflip
Firmware upgrade via menu with internal memory or via USB - DMX interface (UPBOX2) not included
W-DMX included, Wireless Solution transceiver
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% mechanical dimmer
Strobe / shutter1 - 28 flash(s), mechanical
Bedrijfstemperatuur -20° ~ +40°
Display accu self-charging battery backup
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik405W
Power factor0,96
Fysieke eigenschappen
Koeling forced air with fan
Bevestiging any position with quick-lock omega brackets
Signaal aansluiting Seetronic XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN
IP waarde65 for temporary outdoor application, not for fixed installation
