Algemeen
Artikelnummer
21-00365
Merk
ProLights
Artikelnummer fabrikant
ASTRAWASH7PIX
Garantie
2 jaar
Lichtbron
Lichtbron7x40W RGBW Osram Ostar LEDs
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux(4°) 2'013 lm - (56°) 3'543lm @full
Lux(4°) 18'360 lx - (56°) 364lx @5 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens type honeycomb gapless plano-convex optics
Zoom4° - 56° motorised linear zoom
Kleuren
Kleurmenging RGBW / FC
Wit macro's2.800 K ~ 10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
FX generator adjustable foreground/background colour, index, speed, direction
Macros several pre-built pixel macros with adjustable speed
Control Resolution 16-bit dimmer
Body
Pan angle540°
Tilt angle233°
Kleur behuizing RAL 9004
Pan/Tilt resolutiebit 16-bit
Behuizing aluminium structure with high-resistance polycarbonate cover
Aansturing
Protocolen DMX512, RDM, Art-Net, Klingnet, sACN, W-DMX
DMX kanalenmain personality 24 / 27 / 39channel
Display LCD high resolution colour display with autoflip
Firmware upgrade yes, via USB - DMX interface (UPBOX2) not included
W-DMX included, Wireless Solution transceiver
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Display accu self-charging battery backup
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik225W
Output (at 230V)up to 13 units on a single power line
Power factor> 0,93
Fysieke eigenschappen
Koeling forced air with fan
Bevestiging any position with quick-lock omega brackets
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON TRUE1 IN/OUT connectors
IP waarde20
