Lichtbron
Lichtbron150W high-power white LED
CCT8.000K
Luminous flux7'400lm
Lux810lx @10 m
Levensverwachting lichtbron > 50.000 h
CRI78
Optiek
Focus motorised
Kleuren
Kleurenwiel8 colour filters
Effecten
Roterende gobo's7 rotating gobos + open, interchangeable, indexing
Vaste gobo's8 fixed gobos + open
Prisma3f with bi-directional rotation, indexing
Gobo maatouter: 24,2 mm - image: 20 mm - thickness: 0,3 mm
Body
Pan angle540°
Tilt angle270°
Kleur behuizing black, white finishing available
Pan/Tilt resolutiebit 8 / 16bit
Behuizing aluminium structure with hi-resistance polycarbonate cover
Aansturing
Protocolen DMX512, RDM
DMX kanalen12 / 15 channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik225W
Output (at 230V)16 units on a single power line
Fysieke eigenschappen
Bevestiging any position with quick-lock omega brackets
Signaal aansluiting XLR 3p + 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte
43.6 cm
Breedte
30.8 cm
Diepte
23 cm
Gewicht
13.7 kg
