Lamp eigenschappen
KleursysteemRGBWW - Full Color
Vermogen280W
Zoom7,6° - 43° motorised linear zoom
Lichtbron
Lichtbron280W RGB + Warm White LED
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux(7,6°) 2'888 lm - (43°) 3'038lm @full
Lux(7,6°) 6'631 lx - (43°) 532lx @5 m full
Levensverwachting lichtbron > 70.000 h
CRI96 @3.200 K; 93 @5.600 K
R992 @3.200 K; 92,7 @5.600 K
TLCI84 @3.200 K; 84 @5.600 K
TM30 Rf91 @3.200 K; 91 @5.600 K
TM30 Rg104 @3.200 K; 105 @5.600 K
Optiek
Lens diameter125mm
Lens type high-quality glass lens optics
Min. Zoombereik7.6
Max. Zoombereik43
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2.800 K - 8.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros several pre-build macros with adjustable speed
Behuizing
Pan angle540°
Tilt angle250°
Kleur behuizingZwart
Pan/Tilt resolutie8/16bit
Materiaal aluminium die-casting
Aansturing
Protocollen DMX512, RDM, Art-Net, W-DMX
DMX kanalen13 / 15 / 16 / 18 / 22 / 23 / 27channel
Display LCD high resolution colour display with autoflip
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free frequency with adjustable PWM
Display accu self-charging battery backup
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik240W
Output (at 230V)8 units on a single power line
Power factor>0,95
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestiging any position with quick-lock omega brackets
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waarde20, IP20
Gewicht14 kg
Logistieke eigenschappen
Hoogte
23 cm
Breedte
44.3 cm
Diepte
30.8 cm
