Algemeen
Artikelnummer
21-00030
Merk
ProLights
Artikelnummer fabrikant
RA3000PROFILE
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCMY, Kleurenwiel
Vermogen1000W
Zoom6° - 50° motorised linear zoom
Lichtbron
Lichtbron1.000W White LED
CCT linear CTO correction 3.000 K ~ 6.000 K
Luminous flux25'000lm
Lux(6°) 83'500 lx (50°) 1'830lx @5 m
Levensverwachting lichtbron50.000 h
CRI> 90
R975
Optiek
Lens diameter180mm
Min. Zoombereik6
Max. Zoombereik50
Kleuren
Kleurmenging linear CMY
Kleurenwiel6 colour filters
Effecten
FX generator shutter macros with adjustable speed
Roterende gobo's6 rotating gobos + open, interchangeable, indexing
Prisma4f with bi-directional rotation, indexing
Frostdual frost filter system, 1° soft-edge frost gobo, 5° frost wash, with linear 0 - 100% frost filter
Gobo maatouter: 31,6 mm - image: 26 mm - thickness: 1,1 mm
Messen systeem4 single blades: + / - 35°, complete system: + / - 45°
Animatiewiel animation wheel with CW and CCW rotation
Iris5 - 100% motorised iris
EffectenFocus, Frost, Gobo, Iris, Prisma, Profielmessen
Behuizing
Pan angle540°
Tilt angle270°
Kleur behuizingZwart
Pan/Tilt resolutiebit 8 / 16bit
Materiaalflame retardant PC
Aansturing
Protocollen DMX512, RDM, Art-Net, W-DMX
DMX kanalen38 / 39 / 40 / 41channel
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
W-DMX included, wireless solution receiver
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Display accu self-charging battery backup
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik1.288W
Power factor(120 W) 1,0 - (230 W) 0,97
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestigingfast quick lock Omega bracket
Pan / tilt lock for transportation and maintenance
Signaal aansluiting Amphenol XLR 3p + 5p IN/OUT connectors
StroomaansluitingPowerCon True1
IP waarde20, IP20
Gewicht57 kg
Logistieke eigenschappen
Hoogte
91.4 cm
Breedte
53.4 cm
Diepte
40.2 cm
Gewicht
57 kg
