Algemeen
Artikelnummer
21-00028
Merk
ProLights
Artikelnummer fabrikant
PANORAMAIPWBX
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen650W
Zoom3° - 45° motorised linear zoom
Lichtbron
Lichtbron19x40W RGBW Osram Ostar LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(4,5°) 4'452 lm - (36°) 5'803lm @full
Lux(4,5°) 33'893 lx - (36°) 1'764lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens typehigh-quality glass lens optics
Extra optiekendiffuser on outer pixel ring
Min. Zoombereik3
Max. Zoombereik45
Kleuren
KleurmengingRGBW / FC
Wit macro's2.000 K - 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Macrosseveral pre-build pixel macros with adjustable speed
EffectenLed ring, Pixel Control
Behuizing
Pan angle540° - 630°
Tilt angle267°
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 16bit
Materiaalweatherproof IP65 construction
Aansturing
ProtocollenDMX512, RDM, Art-Net, W-DMX
DMX kanalenV1: 18 / 42 / 44 / 120 - V2: 18 / 42 / 44 / 120channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLCD high resolution colour display with autoflip
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° ~ +40°
LED Controlflicker free operation
Slaapstandpower safe mode when lost DMX
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik650W
Output (at 230V)4 units on a single power line
Power factor> 0,95
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN connector, PowerCON TRUE1
IP waarde65 for temporary outdoor application, not for fixed installation, IP65
Gewicht35 kg
Logistieke eigenschappen
Hoogte verpakking
45 cm
Breedte verpakking
63 cm
Diepte verpakking
74 cm
Gewicht verpakking
38 kg
