Lamp eigenschappen
KleursysteemCMY, Kleurenwiel
Vermogen440W
Lichtbron
Lichtbron440W S Osram Sirius HRI
CCTon wheel 2.500 K and 3.200 K + CTB
Luminous flux12'457lm
Lux317'565lx @10 m
Levensverwachting lichtbron1.500 h
CRI80
Optiek
Lens diameter167mm
Lens typehigh-quality glass lens optics
Focusmotorised with auto-focus
Min. Zoombereik2
Kleuren
KleurmengingCMY colour system on 3 gradually fading colour wheels
Kleurenwiel13 dichroic filters on 3 independent colour wheels
Effecten
FX generatorprisms overlap for spectacular aerial effects
Roterende gobo's9 rotating gobos + open, interchangeable, indexing
Vaste gobo's15 fixed gobos + open
Prisma16f with bi-directional rotation, indexing
Linear prisma6f with bi-directional rotation, indexing
Frostlinear 0 - 100% frost filter
Gobo maatouter: 15,8 mm - image: 9 mm - thickness: 0,3 mm
EffectenFocus, Frost, Gobo, Prisma
Behuizing
Pan angle630° - 540°
Tilt angle230°
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, Art-Net, W-DMX
DMX kanalen19 / 22 / 28channel
DisplayLCD high resolution colour display with autoflip
Firmware upgradevia menu with internal memory or via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% mechanical dimmer
Strobe / shutter1 - 28 flash(s), mechanical
Bedrijfstemperatuur-20° ~ +40°
Slaapstandpower safe mode when lost DMX
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik522W
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingSeetronic XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON TRUE1 IN connector, PowerCON TRUE1
IP waarde65 for temporary outdoor application, not for fixed installation, IP65
Gewicht39 kg
Logistieke eigenschappen
Hoogte verpakking
42 cm
Breedte verpakking
54 cm
Diepte verpakking
85 cm
Gewicht verpakking
38 kg
