Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen60W
Lichtbron
Lichtbron60W RGBW Osram Ostar LEDs
CCTCCT control through dedicated DMX channel
Lux11'120lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diameter100mm
Min. Zoombereik4
Kleuren
KleurmengingRGBW / FC
Wit macro's2.000 K ~ 8.000K
Kleurenwielvirtual colour wheel with macros
Behuizing
Pan angle° with 360° continuous rotation
Tilt angle° with 360° continuous rotation
Kleur behuizingZwart, black
Pan/Tilt resolutiebit 8 / 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM
DMX kanalen14 / 16 / 18channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Slaapstandpower safe mode when lost DMX
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik82W
Output (at 230V)15 units on a single power line
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON IN/OUT connectors, PowerCon
IP waarde20, IP20
Gewicht4 kg
Logistieke eigenschappen
Hoogte verpakking
23 cm
Breedte verpakking
28 cm
Diepte verpakking
37 cm
Gewicht verpakking
5 kg
