Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen20W
Aansturing
Stand Alonepush encoder
Lichtbron
CCTCCT control through dedicated DMX channel
Luminous flux753 lm @3.200 K; 889 lm @5.600 K
Lux3.349lx @5 m 3.200K; 3.811lx @5 m 5.600K
Levensverwachting lichtbron> 90.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI96,7 @3.200K; 96,1 @5.600K
R991,7 @3.200K; 98,6 @5.600K
TLCI95 @3.200K; 99 @5.600K
TM30 Rf93,6 @3.200K; 94,1 @5.600K
TM30 Rg104,4 @3.200K; 102,9 @5.600K
Optiek
Lens diameter60mm
Min. Zoombereik5
Kleuren
Kleurmengingtunable white
Effecten
Macrosbuilt-in white presets
Behuizing
Kleur behuizingZwart
Aansturing
DMX kanalen1 / 2 / 3 / 4 / 9ch
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLED display user interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMfor remote addressing and parameter configuration
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1-30 Hz, electronic
BedrijfstemperatuurTa -10 to +45 °C (+14 to +113 °F)
LED Controlflicker free frequency with adjustable PWM
Selecteerbare PWM frequentie600 to 25000 Hz (selectable steps)
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik25W
Power factor> 0,9
Fysieke eigenschappen
Koelingfan-free with natural convection
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
StroomaansluitingPowerCon TRUE1
IP waardeIP20
Gewicht1kg kg
Overige eigenschappen
Lichtbron1 x 20W Warm White + Cold White LEDs
Singlecolor LED
Logistieke eigenschappen
Hoogte verpakking
19 cm
Breedte verpakking
26.5 cm
Diepte verpakking
21 cm
Gewicht verpakking
1.9 kg
