Algemeen
Artikelnummer
23-00054
Merk
ProLights
Artikelnummer fabrikant
LUMIPIX12QTOUR
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBW - Full Color
Vermogen120W
Lichtbron
Lichtbron12x10W RGBW LEDs
CCTCCT control through dedicated DMX channel
Luminous fluxwithout filter: 3'587 lm - with filter: 3'201lm
Luxwithout filter: 2'358 lx - with filter: 2'070lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diameter45mm
Extra optieken15° (opt) - 45° (opt)
Min. Zoombereik15
Max. Zoombereik45
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGBW / FC
Wit macro's2.800 K - 10.000K
Kleurenwielvirtual colour wheel with macros
Effecten
Macrosseveral pre-build pixel macros with adjustable speed
EffectenLed ring
Behuizing
Kleur behuizingZwart, black
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512
DMX kanalen5 / 7 / 9 / 49channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves7 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik94,8W
Output (at 230V)27 units on a single power line
Fysieke eigenschappen
Koelingpassive cooling and fan-free
Bevestigingdouble hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluitingAmphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCon, Seetronic powerCON IN/OUT connectors
IP waarde30, IP20
Gewicht5 kg
Logistieke eigenschappen
Gewicht verpakking
7 kg
