Lamp eigenschappen
Zoom10° - 60° motorised linear zoom
Lichtbron
Lichtbron12x10W RGBW / FC LEDs
Luminous flux(10°) 1'450 lm - (60°) 1'786lm
Lux(10°) 3'144 lx - (60°) 249lx @5 m full
Levensverwachting lichtbron > 50.000 h
Optiek
Lens type plano-convex lens path
Kleuren
Manual colour mode manual adjustment of colour
Kleurmenging RGBW / FC
Kleurenwiel virtual colour wheel with macros
Effecten
Macros built-in white presets
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512
DMX kanalen5 / 7 / 10channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 28 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik120W
Output (at 230V)12 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging double hanging bracket suitable for safe hanging and for floor positioning
Signaal aansluiting XLR 3p + 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON IN/OUT connectors
IP waarde30
Logistieke eigenschappen
Hoogte verpakking
27 cm
Breedte verpakking
35.5 cm
Diepte verpakking
46.5 cm
Gewicht verpakking
6.5 kg
